ForaneĀ® 410A is a refrigerant blend of two eco-friendly HFCs: R-32 and R-125. It works well with all kinds of air conditioners and other cooling devices. ForaneĀ® 410A is the preferred choice for new homes and businesses that need efficient and reliable air conditioning systems, heat pumps, dehumidifiers, chillers and more. ForaneĀ® 410A has more cooling power and pressure than R-22, so it is not compatible with R-22 equipment.
SPECIFICATIONS
| (Meets AHRI 700-2011 Specifications) | Maximum (unless otherwise indicated) | Tolerance |
| Difluoromethane (HFC-32), wt % | 50.0 (nominal) | -1.5%/+ 0.5% |
| Pentafluoroethane (HFC-125), wt % | 50.0 (nominal) | -0.5%/+1.5% |
| Air and Other Non-condensable Gases, vol % | 1.5 | |
| Volatile Impurities, wt % | 0.5 | |
| High Boiling Residue, vol % | 0.01 | |
| Moisture (H2O), ppm by wt | 10 | |
| Acidity, ppm by wt (as HCl) | 1.0 | |
| Chloride, no visible turbidity (indicates about 3 ppm) | Pass | |
| Particulates / solids (visually clean to pass) | Pass |
PROPERTIES
| Appearance | Colorless liquefied gas |
| Odor | Faint, ether-like odor |
| Molecular Mass (g/mole of blend) | 72.59 |
| Bubble point at 1 atm | -60.5Ā°F / -51.4Ā°C |
| Dew Point at 1 atm | -60.5Ā°F / -51.4Ā°C |
| Flammable Limits (LFL, UFL), vol % (1 atm, 25oC) | NA / NA |
| ANSI/ASHRAE Standard 34 Safety Group Classification | A1 |
| Ozone Depletion Potential (ODP) (CFC-11 = 1.0) | 0 |
| Global Warming Potential (GWP) (CO2 = 1.0) | 2,100 |
