R600a Technical, Physical, And Chemical Data Properties
R600 refrigerant fluid doesnât degrade or damage the compressor and other parts of condensing unit or refrigeration unit because it has no impurities substance.
The overall physical properties are also very standard. R600a refrigerant has 58.1 molecular weight, -11.7 ÂșC boiling temperature, 135ÂșC critical temperature, and 0 ÂșC of glide temperature.
The possibility of r600a refrigerant gas mixing with oil is very low as there is outstanding adaptability with oil and lubricant.Â
| Properties | Value |
| Melting point | -255.3 â -159.6â, |
| Vapour pressure (@70 F) | 45 psia |
| Initial boiling point | 10.9â- 11,73° C @ 1013 hPa |
| Auto-ignition temperature | 287 °C |
| Vapour density | 2,06 (air = 1) |
| Latent heat at 25ÂșC | 332 KJ/KG |
| Volatile Component (%vol) | 100 |
| Autoignition | -778 â (420â) |
| Lower Flammability limit weight | 0.043 kg/n3 |
| Lower Flammability Limit by volume | 1.8%, |
| Upper Flammability Limit | 8.4 % |
| Flash Point | -117â (-83â) Closed Cup |
| Auto-igniÆon temperature (°C) | 462 (365) |
| Vapour density (Air = 1) | 2.06 |
| Global Warming Potential | 3 |
| Flammability | Highly Flammable |
| Ozone Depletion potential | 0 |
What Is R600a Refrigerant Gas Used For?
R600 is mainly the first choice instead of R12 and R134a refrigerant because of its very low GWP.
Though the R600 refrigerant gas has a very high risk of flammability and high density than air, It is risky to use.
But it reduces the energy consumption of R134a and R12 refrigerant gas as their replacement alternative.
This natural ISObutane refrigerant gas doesnât need to be recovered as it is hydrocarbon fluid.
It requires a semi-synthetic or a blend of mineral and Alkylbenzene oil.
It is one kind of safe refrigerant as non-toxic and has no harmful fluorine, affecting greenhouse gases.
Application Of R600a Refrigerant Gas?
R600a refrigerant gas is used in high-temperature refrigerant applications for any domestic, industrial, and commercial applications.
It is suitable for small air condensing units, air-cooled condensing units, outdoor ac units, or commercial refrigeration units.
When using the isobutane R600a refrigerant gas in domestic applications, it is easier to identify when there is a leakage.
It is undoubtedly perfect to use in any Rotary compressor, Bitzer compressor, Copeland Compressor, or Danfoss compressor in any fridges, freezers, display units, drink dispensers, chillers, outdoor condensing unit.
